TCL 43P635 User Manual

EN
10
English
Chapter 3 - Basic TV operations
Remote control buttons
Here are the navigation direction buttons and the
OK
button on the remote control that you may use
frequently.
OK
▲/▼/◄/►
Accessing channels
Using the Navigation Direction buttons:
press
▲/▼
on the remote control to scroll through the
channels.
Using the OK button
: press the
OK
button to display
the channel list and press
▲/▼/◄/►
and
OK
to
select channels.
Using the P+/P- buttons:
press the
P+/P-
buttons on
the remote control to scroll through the channels.
Using the button:
press
t
o display the
virtual remote control keyboard
,
then you can use
the numeric buttons, or the
List
button to operate
accordingly.
Watching connected devices
Press on the remote control to display the source
list. Press
▲/▼
to select TV or other input sources
and press
OK
to conrm.
Adjusting volume
Volume control
: press the
/
buttons on the
remote control to increase or decrease the volume.
Sound mute
: press the button to temporarily mute
the sound. Press this button again or the button to
restore the sound.
Accessing Smart TV homepage
Allows you to enjoy Internet Applications (Apps) and
specially adapted Internet websites, and perform
system settings for your TV. You can make controlling
with the TV remote control.
WARNING:
• Congure the network settings before using Smart
TV applications.
• Slow responses and/or interruptions may occur,
depending on your network conditions.
• If you experience a problem using an application,
please contact the content provider.
• According to circumstances of the content provider,
an application’s updates or the application itself may
be discontinued.
• Depending on your country's regulations, some
applications may have limited service or not be
supported.
• Changes in application content may be made
without prior notice by the service provider.
1.
Press on the remote control to display the Smart
TV homepage.
2.
Press
▲/▼/◄/►
and
OK
to enter the desired
Apps, functions or settings.
3.
Press to return to the homepage.
Note: Since the connection with Internet takes
time, it’s recommended that you wait a few
minutes to use the Smart TV feature after
activation of TV from standby.
Using Settings menu
Allows you to adjust TV settings, such as picture and
sound.
1.
Press on the remote control to display the
dashboard menu.
2.
Select
Settings
and press
OK
to enter the settings
menu.
3.
In submenus, press
▲/▼
to select menu options,
then press
OK/►
to enter the option list, or the
corresponding submenu, or press
OK
to toggle on
or o󰀨, or press
◄/►
to adjust the setting.
4.
Press to return to the previous menu.
Note: Setting
LED motion clear
on will make fast
moving images clearer by controlling the
LED backlight, but the picture will be darker
and more ickering than with
LED motion
clear
o.

TCL 43P635 Specifications

General

Color depth	10 bit
Screen shape	Flat
Response time	15 ms
Display diagonal	43 \
Progressive scan	Yes
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	60 Hz
Peak luminance ratio	74 %
LED backlighting type	Direct-LED
Viewable size diagonal	1080 mm
Contrast ratio (typical)	-
Display diagonal (metric)	109.2 cm
Display refresh rates supported	50 Hz, 60 Hz
Motion interpolation technology	PPI (Picture Perfomance Index) 2300
Dynamic contrast ratio marketing name	Mega Contrast
Audio decoders	Dolby Audio
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
Audio output channels	2.0 channels
HDCP version	2.2
RF connector type	F, IEC
HDMI ports quantity	3
USB 2.0 ports quantity	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Bluetooth profiles	A2DP, HID, SBC
Cables included	AC
Remote control type	RC833
Package type	Box
Package depth	125 mm
Package width	1100 mm
Package height	658 mm
Package weight	8600 g
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Analog signal format system	NTSC, PAL, PAL I, SECAM, SECAM B/G, SECAM D/K
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Programming period	8 day(s)
Number of OSD languages	29
Firmware upgradeable via	Network, USB
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Digital Living Network Alliance (DLNA) specification	DMP
Stand type	Legs stand
Product color	Anthracite
Panel mounting interface	200 x 200 mm
Game features	Auto Low Latency Mode (ALLM)
Processor cores	4
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG, PNG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Video compression formats	AV1, H.264, H.265, VP9
Picture processing technology	TCL AiPQ 2.0 Engine
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Music apps	Amazon Music, Deezer, Spotify, TIDAL, TuneIn, YouTube Music
Video apps	Amazon Prime Video, Apple TV, BBC iPlayer, Disney+, Google TV, HBO, Netflix, Twitch, Vimeo, YouTube
Smart modes	Dynamic, Game, Movie, Sports
App distribution platform	Google Play
Operating system installed	Google TV
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.2
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (max)	90 W
Power consumption (standby)	0.5 W
Power consumption (typical)	48 W
Color gamut	81 %
Cord length	1.5 m
User memory	9.2 GB
Doesn't contain	Lead
Warranty period	- year(s)
Processor frequency	1.3 GHz
Processor architecture	ARM rtd288o
Pallet width	1200 mm
Pallet height	1440 mm
Pallet length	800 mm
Quantity per truck	396 pc(s)
Quantity per pallet	12 pc(s)
Number of pallets per truck	33 pc(s)
Internal memory	10200 MB
Repairability index	6.8

Weight and Dimensions

Stand width	838 mm
Depth (with stand)	185 mm
Width (with stand)	957 mm
Height (with stand)	603 mm
Weight (with stand)	6300 g
Depth (without stand)	79 mm
Height (without stand)	558 mm
Weight (without stand)	6200 g
