TCL 50P615 User Manual

TCL 50P615
20 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #16 background imageLoading...
Page #16 background image
16
Reset Shop
Allows you to reset the TV to factory default settings.
1.
Press on the remote control to display the
homepage, Press ▲/◄/► to select
(Settings) >
Device Preferences > Reset
and press
OK
to enter.
2.
Press
/
to select
Factory data reset
and press
OK
to enter. Then select
Erase everything
and
press
OK
to confirm.
3.
Enter 1234 or the PIN according to the on-screen
prompt.
4.
Select
OK
and press
OK
toconrm.
5.
The
Initial setup
wizard appears. Follow the
instructions in the section
Initial setup
.
Password in Parental Control
-
The default password is 1234. You can change it to a
new one.
-
The super password is 0423. If you forget your code,
enter the super password to override any existing
codes.
Using the Hands-free TV Voice Control
(* not available for some models)
Before using the hands-free TV voice control, connect
the TV to the network and make sure it can access the
Googlewebsiterst.Thenfollowthestepsbelowto
access.
1. Turn the built-in MIC switch (next to the power button)
to on before using this function.
2. Access the Android TV homepage by pressing on
the remote control.
3. Select
(Settings) > Quick Settings > "Ok Google"
detection
and press
OK
to turn it on. You can also set
it by selecting
(Settings) > Device Preferences >
Google Assistant > "Ok Google" detection.
4. Say “OK Google” to activate it.
Notes
:
-
The availability of hands-free TV voice control
depends on your region/country/language and
your model. For details, please refer to your local
dealer.
-
A quiet surrounding is required for better function
when using it. The recommended using distance
is within 2 meters in front of TV set.
-
Turn the built-in MIC switch to off if you are not
going to use it. Or set the
"
Ok Google
"
detection
to off.
-
Standby power consumption will increase because
the built-in MIC is always listening when the
Google Assistant or voice control with the built-in
MIC is enabled.
Using more of your TV

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 50P615 and is the answer not in the manual?

TCL 50P615 Specifications

General IconGeneral
Screen shapeFlat
Response time10 ms
Display diagonal50 \
Display brightness300 cd/m²
Display technologyLCD
Native aspect ratio-
Native refresh rate60 Hz
Peak luminance ratio65 %
LED backlighting typeDirect-LED
Viewable size diagonal1260 mm
Display diagonal (metric)127 cm
Motion interpolation technologyPPI (Picture Performance Index) 1500
Dynamic contrast ratio marketing nameMega Contrast
Audio decodersDolby Digital, Dolby Digital AC4
RMS rated power16 W
Number of speakers2
Auto volume levelerYes
Product colorBlack
Mercury content0 mg
Heavy metals freeHg (mercury)
Panel mounting interface200 x 300 mm
AC input voltage220 - 240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (max)130 W
Power consumption (standby)0.29 W
Power consumption (typical)73 W
Package depth145 mm
Package width1265 mm
Package height760 mm
Package weight13800 g
Processor cores4
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG, PNG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technologyTCL IPQ 2.0 Engine
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
RF connector typeF, IEC
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
Tuner typeAnalog & digital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Video appsAmazon Prime Video, Netflix, YouTube
Smart modesGame, Movie, Sports
Lifestyle appsGoogle Apps
Operating system version9.0
Operating system installedAndroid
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth profilesA2DP, HID
CertificationCE
Remote control typeRC802N4
Repairability index6.8
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)266 mm
Height (with stand)705 mm
Weight (with stand)10400 g
Depth (without stand)78 mm
Width (without stand)1120 mm
Height (without stand)660 mm
Weight (without stand)10100 g
