TCL 55C815 Manual

7
Getting Started
Network Connection
Your TV will require an internet connection to operate all functions. Data usage charges may apply.
Please refer to your Internet Service Provider (ISP) for additional information.
To access the Internet, you must subscribe to high speed broadband Internet service with your Internet service
provider (ISP).
Your TV can be connected to your home network in two ways:
• Wired, using the RJ45 (LAN) connector on the back panel.
• Wireless, using the internal wireless and your home wireless network.
Note: Instructions below are just the usual ways to connect your TV to the wired or wireless network. The connection
method may be different depending on your actual network conguration. If you have any questions about your home
network, please refer to your ISP.
Connecting to a wired network
To connect to a wired network:
1. Ensure you have:
• An Ethernet cable long enough to reach your TV
• A router or modem with an available Ethernet
port
• A high-speed Internet connection
• An Ethernet (LAN) port on the back of the TV
2. Connect your Ethernet cable to the router and to
the Ethernet port on the back of the TV.
3. Use the Network menu to configure the TV.
Connecting to a wireless network
To connect to a wireless network:
1. Ensure you have:
• A router broadcasting a high-speed wireless
signal
• A high-speed Internet connection
2. Use the Network menu to configure the TV.
Modem Internet
TV Set
Router
Ethernet
Port on the
back panel
Wireless Router
Modem
TV Set
Built-in wireless
connection

TCL 55C815 Specifications

General

Screen shape	Flat
Response time	10 ms
Display diagonal	55 \
Display brightness	470 cd/m²
Display technology	QLED
Native aspect ratio	-
Native refresh rate	50 Hz
Peak luminance ratio	72 %
LED backlighting type	Edge-LED
Supported video modes	2160p
Viewable size diagonal	1390 mm
Display diagonal (metric)	139.7 cm
Supported graphics resolutions	3840 x 2160
Motion interpolation technology	PPI (Picture Perfomance Index) 2800
Dynamic contrast ratio marketing name	Mega Contrast
RF connector type	F, IEC
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio Return Channel (ARC)	Yes
Ethernet LAN (RJ-45) ports	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Video apps	Amazon Prime Video, Netflix, YouTube
Smart modes	Game, Movie, Sports
Lifestyle apps	Google Apps
Operating system version	9.0
Operating system installed	Android
Number of OSD languages	29
Firmware upgradeable via	Network, USB
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HIN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWA, TUR, UKR
Audio decoders	DTS, Dolby Atmos, Dolby Digital, DTS-HD, Dolby Digital AC4, Dolby TrueHD
RMS rated power	35 W
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth profiles	A2DP, HID
AC input voltage	220 - 240 V
Energy efficiency scale	A to G
Power consumption (max)	180 W
Power consumption (standby)	0.28 W
Power consumption (typical)	112 W
Product color	Black
Mercury content	0 mg
Heavy metals free	Hg (mercury)
Panel mounting interface	400 x 200 mm
Processor cores	4
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG, PNG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPEG2, MPG, TS, VP9, WEBM, WMV
Picture processing technology	TCL IPQ 2.0 Engine
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Remote control type	RC602S6+RC802N4
Package depth	168 mm
Package width	1400 mm
Package height	875 mm
Package weight	23800 g
Battery type	AAA
Battery technology	Alkaline
Truck type	87 cbm
Pallet height	1870 mm
Pallet length	800 mm
Pallet weight	255400 g
Pallet net weight	15000 g
Quantity per truck	280 pc(s)
Quantity per pallet	10 pc(s)
Number of pallets per truck	28 pc(s)
Maximum number of stacking cartons	3 pc(s)

Weight and Dimensions

Depth (with stand)	295 mm
Height (with stand)	783.4 mm
Weight (with stand)	17800 g
Depth (without stand)	64 mm
Width (without stand)	1227.4 mm
Height (without stand)	739.7 mm
Weight (without stand)	17400 g
