Optional - To mount on a wall
(wall mount not included)
Preparation must be done before mounting your TV on a wall.
To mount on a wall
1-1
Place your TV on a soft, cushioned surface.
Remove the 2 screws on the back of the TV.
1-2
2 3
75” 43”/50”/55”/65”
43”/50”/55”
/65”/75”
The VESA number is the horizontal and vertical measurement of the mounting holes. For
example, 200X200 refers to the fact that the mounting measurements are 200mm horizontally
and 200mm vertically.
Follow the instructions that come with the wall mount.
Your wall mount must be able to bear a minimum of five times the TV’s net weight to avoid
causing damage.
Purchase a VESA 200x200 (4 M6x12mm screws)
If you are mounting your TV to the wall, don’t attach the stands.
To mount your TV to the wall, purchase a VESA wall mount
Models of 43’’
Models of 50’’ Purchase a VESA 200x200 (4 M6x12mm screws)
Models of 55’’ Purchase a VESA 200x200 (4 M6x12mm screws)
Models of 65’’ Purchase a VESA 200x200 (4 M6x12mm screws)
Models of 75’’ Purchase a VESA 300x300 (4 M6x25mm screws)
Place your TV on a soft, cushioned surface.
Remove the 4 screws on the back of the TV.
Screw the VESA bracket tightly onto the
back cover with 4 VESA screws.
Follow the instructions that come with the
wall mount to hang the TV on the wall.
6
Note: 1. For the 43/50/55/65 model, if you select wall mounting, you should connect to
the Ethernet which placed on the back of the TV before mounting your TV on a wall.
2. Do not place your TV in a location exposed to direct sunlight, heat, fire, or moisture.
Exposure will damage the TV.
