TCL 65P635 User Manual

EN
8
English
Additional remote control
Installing batteries
1.
Push to open the back cover as illustrated.
2.
Insert two AAA batteries according to the polarities
marked on the battery case.
3.
Replace the back cover as illustrated.
Getting started
To switch the sound o󰀨 and back on.
Standby / quit standby.
Numeric buttons
To enter channel numbers or a digit.
To access TCL Channel.
LIST
Add an entity to Watchlist (Available only in Google TV
mode.). Or future functions.
/
To control the volume.
To display programme information, if available.
To display the dashboard menu.
P /
To change channels.
To access the Smart TV homepage.
To display the Quick Settings panel. Or to perform the
corresponding function as indicated on screen.
▲/▼/
◄
/
► Navigation direction buttons.
OK
To conrm an entry or selection.
To return to the previous menu or quit an App.
To select input source.
EXIT
To exit the on-screen menu.
LANG
To select an audio language available for selected digital TV
programme.
GUIDE
To access the Electronic Programme Guide (only available
for digital channels).
TEXT
To toggle Teletext on or o󰀨.
SUBT.
To select a subtitle language available for selected digital TV
programme.
Colour buttons
To select tasks or Teletext pages; to be used for HbbTV
function.
To start fast reverse.
To pause playback.
To start fast forward.
ZOOM
To select the screen mode.
Note: You are recommended to use the full screen mode.
Do not use the display mode with black bars on both sides
of the picture (such as 4:3) for a long time; otherwise the TV
screen may be damaged permanently.
To start playback.
To stop playback.
NETFLIX
To access Netix if available.
prime video
To access Prime video if available.

TCL 65P635 Specifications

General

Color depth	10 bit
Screen shape	Flat
Response time	15 ms
Display diagonal	65 \
Progressive scan	Yes
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	60 Hz
Peak luminance ratio	73 %
LED backlighting type	Direct-LED
Viewable size diagonal	1640 mm
Contrast ratio (typical)	-
Display diagonal (metric)	165.1 cm
Display refresh rates supported	50 Hz, 60 Hz
Motion interpolation technology	PPI (Picture Perfomance Index) 2300
Dynamic contrast ratio marketing name	Mega Contrast
Audio decoders	Dolby Audio
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
Audio output channels	2.0 channels
HDCP version	2.2
RF connector type	F, IEC
HDMI ports quantity	3
USB 2.0 ports quantity	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (max)	145 W
Power consumption (standby)	0.5 W
Power consumption (typical)	98 W
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Bluetooth profiles	A2DP, HID, SBC
Cables included	AC
Remote control type	RC833
Package type	Box
Package depth	155 mm
Package width	1645 mm
Package height	997 mm
Package weight	20100 g
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Analog signal format system	NTSC, PAL, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Programming period	8 day(s)
Number of OSD languages	29
Firmware upgradeable via	Network, USB
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Digital Living Network Alliance (DLNA) specification	DMP
Stand type	Legs stand
Product color	Black
Panel mounting interface	200 x 200 mm
Game features	Auto Low Latency Mode (ALLM)
Processor cores	4
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG, PNG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Video compression formats	AV1, H.264, H.265, VP9
Picture processing technology	TCL IPQ 2.0 Engine
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Music apps	Amazon Music, Deezer, Spotify, TIDAL, TuneIn, YouTube Music
Video apps	Amazon Prime Video, Apple TV, BBC iPlayer, Disney+, Google TV, HBO, Netflix, Twitch, Vimeo, YouTube
Smart modes	Dynamic, Game, Movie, Sports
Operating system version	ATV 12.0
App distribution platform	Google Play
Operating system installed	Google TV
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.2
Internal memory	10200 MB
Repairability index	6.7
Color gamut	81 %
Cord length	1.5 m
User memory	9.2 GB
Doesn't contain	Lead, Mercury (element)
Warranty period	- year(s)
Processor frequency	1.3 GHz
Processor architecture	ARM rtd288o
Pallet width	1650 mm
Pallet height	2120 mm
Pallet length	800 mm
Quantity per truck	240 pc(s)
Quantity per pallet	10 pc(s)
Number of pallets per truck	24 pc(s)

Weight and Dimensions

Stand width	1275 mm
Depth (with stand)	301 mm
Height (with stand)	878 mm
Weight (with stand)	14300 g
Depth (without stand)	81 mm
Width (without stand)	1446 mm
Height (without stand)	826 mm
Weight (without stand)	14200 g
