EN
11
English
Chapter 4 - Using more of your TV
Installing channels
This section describes how to search and store
channels automatically. This may be done in any of
the cases below:
- you have skipped the channel installation step in the
initial setup;
- you are prompted that there are no channels in TV
mode;
- you want to update your channels.
1.
In TV mode, press
on the remote control
and select
Settings > Channels and inputs >
Channel > Channel scan
. Press
OK /
to enter.
2.
The TV installs and arranges channels according
to your country or region. Press
/
to select
Country/Region
, and press
OK /
to enter.
Enter the password you have set in the
Settings
>
System
>
Lock
menu. Press
/
to select your
country or region and press
OK
to conrm.
3.
Press
/
to select
Automatic search
and
press
OK
to enter.
4.
Press
/
to select
Tuner mode
and press
/
to select
Cable
,
Antenna
or
Satellite
.
(Note:
Satellite
option is available only in selected
models.)
5.
Press
/
to select other options to congure.
6.
After conguration is completed, press to select
Search
and press
OK
to start scanning channels.
7.
The channel search may take a few minutes. After
the automatic search, channels are arranged in a
preset order. If you want to edit the channel list,
press
on the remote control, select
Settings
> Channels and inputs > Channel > Edit
Channels
and press
OK
to enter.
Note:
Edit Channels
option is not available
when
Tuner mode
is set to
Antenna
and
Country/Region
is set to United Kingdom.
Common interface
Encrypted digital TV channels can be decoded with a
common interface module and a card provided by a
digital TV service operator.
The common interface module may enable several
digital services, depending on the operator and
services you choose (for example, pay TV). Contact
your digital TV service operator for more information
about services and terms.
Using the common interface module
WARNING: Switch o󰀨 your TV before inserting a
common interface module. Be sure to follow the
instructions described below. Wrong insertion of
a common interface module may damage both the
module and your TV.
1.
Following the directions printed on the common
interface module, gently insert the module into the
common interface slot on the TV.
2.
Push the module in as far as it will go.
3.
Turn on the TV and wait for the common interface
function to be activated. This may take several
minutes.
Note: Do not remove the common interface
module from the slot. Removing the module
will deactivate the digital services.
Accessing common interface services
After inserting and activating the common interface
module, press
on the remote control, select
Settings > Channels and inputs > Channel >
Common interface
and press
OK
to enter.
This menu option is only available if the common
interface module is correctly inserted and activated.
On-screen applications and content are provided by
your digital TV service operator.
Using subtitles
You can enable subtitles for each TV channel.
Subtitles are broadcast via Teletext or DVB-T/DVB-C/
DVB-S/DVB-T2/DVB-S2 digital broadcasts. With
digital broadcasts, you have the additional option of
selecting a preferred subtitle language.
Turning on/o󰀨 subtitles
1.
Press
on the remote control, select
Settings >
Channels and inputs > Channel > Subtitle
and
press
OK /
to enter.
2.
Select the
Subtitle
option, and press
OK
to toggle
between on or o󰀨.
3.
Press to return to the previous menu.
Enabling subtitle languages on digital TV
channels
1.
Press
on the remote control, select
Settings
> Channels and inputs > Channel > Subtitle >
Digital subtitle language 1st
and press
OK
/
to
enter.
2.
Press
/
to select a subtitle language as your
preferred language and press
OK
to conrm.
3.
Press
/
to select
Digital subtitle language
2nd
and press
OK
/
to enter.
4.
Press
/
to select a secondary subtitle
language and press
OK
to conrm.
5.
Press to return to the previous menu.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 85C845 and is the answer not in the manual?

TCL 85C845 Specifications

General IconGeneral
TimeshiftNo
Video appsAmazon Prime Video, Apple TV, Disney+, Google TV, HBO, Netflix, Twitch, YouTube
Screen mirroringYes
Operating system version11
Operating system installedGoogle TV
Headphone outputs1
RF ports quantity2
HDMI ports quantity4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Common interface Plus (CI+) version1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Basic hotel mode-
Programming period8 day(s)
Screen shapeFlat
Response time5.7 ms
Display diagonal85 \
Display brightness600 cd/m²
Display technologyQLED
Native aspect ratio16:9
Native refresh rate144 Hz
LED backlighting typeMini LED
Contrast ratio (typical)5000:1
Display diagonal (metric)214 cm
Motion interpolation technologyPPI (Picture Performance Index) 4600
Dynamic contrast ratio marketing nameMega Contrast
Product colorBlack
Panel mounting interface600 x 400 mm
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version5.2
Tuner typeDigital
Number of tuners1 tuner(s)
Digital signal format systemDVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2
AMD FreeSync typeFreeSync Premium Pro
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technologyTCL AiPQ 3.0 Processor
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Package depth245 mm
Package width2055 mm
Package height1318 mm
Package weight63200 g
Audio decodersDTS, Dolby Atmos, DTS Virtual:X, DTS-HD
RMS rated power70 W
Power consumption (typical)- W
Battery weight15 g
Warranty period2 year(s)
Country of originPoland
Battery technologyAlkaline
Pallet net width2200 mm
Pallet net height1458 mm
Pallet net length800 mm
Pallet net weight226500 g
Quantity per pallet layer3 pc(s)
Master (outer) case weight64500 g
Quantity per master (outer) case1 pc(s)
Maximum number of stacking cartons2 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)350 mm
Height (with stand)1156 mm
Weight (with stand)45100 g
Depth (without stand)84 mm
Width (without stand)1893 mm
Height (without stand)1086 mm
Weight (without stand)40100 g
