5
DO NOT RETURN TO STORE
TCL SUPPORT:
support.tcl.com
1-800-825-6747
contact us first
with any questions
WE ARE
READY TO
HELP
BE CAREFUL WHEN REMOVING
THE AIR CONDITIONING UNIT
BEFORE YOU BEGIN
Read the instructions completely and carefully
Save these instructions for local inspector’s use
Observe all governing codes and ordinances
Note to installer – be sure to leave these instructions with the consumer
Note to consumer – keep these instructions for future reference
We recommend 2 people install this product
Proper installation is the responsibility of the installer
Product failure due to improper installation is not covered under warranty
What’s in the box
NO. APPEARANCE PART NAME QUANTITY
2
Through-The-Wall Air
Conditioner
1
3
Remote Control
1
4
Trim Frame 1
(Left & Right legs)
2
5
Trim Frame 2
(Top & Bottom legs)
2
6
Aluminum Grill
1
7
Rear Plastic Grill
1
8
1/2” Long Hex-Head Screw
4
9
Grounding Wire with Tooth
Washer
1
DIMENSION PART NAME QUANTITY
1’’x3/4’’x14’’ Seal sponge 2
1’’x3/8’’x14’’ Seal sponge 2
1’’x3/8’’x25’’ Seal sponge 3
1’’x1 1/2’’x25’’ Seal sponge 3
1’’x1 1/2’’x14’’ Seal sponge 2
1’’x1 1/2’’x84’’ Seal sponge 1
3 3/ 4’’x1 1/2’’x4’’ Seal cotton 4
3/4’’x1 1/2’’x17’’ Seal cotton 2
Tools needed: Drill and drill bits, Phillips head screwdriver, Flat headed screwdriver, tape measure,
level, scissors or knife, pencil.
