TCL Alto 7+ User Manual

13
4 +/-
Press to increase or decrease the volume level.
5 Remote control sensor
Receive signals from the remote control.
6 LED indicator
Red: in standby mode.
Purple: in HDMI mode.
Green: in AUX mode.
Blue: in Bluetooth mode.
Yellow:inOpticalmode.
White: in USB mode.
7 IR pass-through cable connector
8 AUX input connector
9 AC input power connector
10 HDMI ARC connector
11 Optical input connector
12 USB Type A connector (only for music playback)
TS7010_UM_US_EN_print_190118a.indd 13 25/2/2019 11:49 AM

TCL Alto 7+ Specifications

General

Brand	TCL
Model	Alto 7+
Category	Speaker System
Language	English
