9
To mount on a wall
Preparation must be done before mounting your TV on a wall.
Note: Do not place your TV in a location exposed to direct sunlight, heat, fire, or moisture.Exposure
will damage the TV.
To mount your TV to the wall, purchase the one of the following VESA wall mounts:
•55" model VESA 300x300, 4 M6x12mm screws
•65" model VESA 400x300, 4 M6x12mm screws
•75" model VESA 400x300, 4 M6x16mm screws
The VESA number is the horizontal and vertical measurement of the mounting holes. For
example, 200 x 200 indicates that the mounting holes are spaced 200mm horizontally and
200mm vertically.
Follow the directions supplied with the wall mount to mount the TV to the wall.
Caution: Your wall mount must be able to bear a minimum of five times the TVs net weight to
avoid damage.
Note: The wall mount bracket and the screws are not included.
Warning: This product should only be mounted by a professional installer.
Warning: Never install or mount this product to the ceiling with the screen side facing down.
Installing or mounting this product to the ceiling or the underside of a structure or surface is
hazardous and may result in personal injury and/or property damage.
1 2
Place your TV on a soft, cushioned surface. Screw the VESA
bracket tightly onto the back cover with 4 VESA screws.
Follow the instructions that come with the wall mount to
hang the TV on the wall.
