TCL S643W User Manual

27
Connect your wireless Subwoofer to
the Soundbar
When the wireless Subwoofer is connected, you can enjoy
powerful deep bass sounds and a truly immersive audio
experience.
Auto pairing
Make sure both the Soundbar and wireless Subwoofer
areconnected to the power supply and are turned on.
THE SUBWOOFER WILL PAIR AUTOMATICALLY WITH
SOUNDBAR UPON FIRST USE. In case of a problem, take
the following steps to manually pair:
Press the button on the Subwoofer for 3 seconds until
indicator light ashing fast beside pair button.
Press the button on the Soundbar for 5 seconds.
When indicator light turn solid on the Subwoofer.
Pairing is successful.
If you have more than one devices to be connected, please
connect the next one after connecting the previous one
successfuly.
>3s
>5s

TCL S643W Specifications

General

Audio decoders	DTS Virtual:X, Dolby Audio, Dolby Digital Plus
Equalizer modes	Bass Boost, Game, Movie, Music, Sport, Standard, Voice
RMS rated power	240 W
Audio output channels	3.1 channels
Audio Return Channel (ARC)	Yes
Impedance	8 Ω
Number of speakers	3
Subwoofer location	Separate
Subwoofer connectivity	Wireless
Subwoofer frequency range	40 - 180 Hz
Product color	Black
Volume control	Touch
Apple AirPlay 2 support	No
Operating temperature (T-T)	0 - 45 °C
HDMI version	1.4
Bluetooth version	5.3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Soundbar power consumption	50 W
Power consumption (standby)	0.5 W
Subwoofer power consumption	30 W
Frequency range	180 - 20000 Hz
Bluetooth profiles	A2DP, AVRCP
Number of remote control batteries	2
Transmitting power	10 dBmW

Weight and Dimensions

Depth	97.6 mm
Width	810 mm
Height	62 mm
Cord length	1.5 m
Soundbar weight	2000 g
Subwoofer width	195 mm
Subwoofer height	320.4 mm
Subwoofer weight	3000 g
