18
(18)
Specifications
■
GENERAL
Power supply
AC 220 V to 240 V,
50/60 Hz
Power consumption 42 W
Power consumption
in standby mode
(Network Standby
Off)
0.2 W
Power consumption
in standby mode
(Network Standby
On with Wireless
LAN)
2.0 W
Power consumption
in standby mode
(Network Standby
On with Wired
LAN)
2.0 W
Dimensions
(W×H×D)
375 mm × 220 mm ×
197 mm
Mass Approx. 5.9 kg
Operating
temperature range
0 °C to +40 °C
Operating humidity
range
35 % to 80 % RH
(no condensation)
■
AMPLIFIER SECTION
Output power
Front speaker (L/R):
20 W + 20 W
(1 kHz, T.H.D. 1.0 %,
8 , 20 kHz LPF)
Front speaker (Center):
20 W
(1 kHz, T.H.D. 1.0 %,
8 , 20 kHz LPF)
Subwoofer:
40 W
(100 Hz, T.H.D. 1.0 %,
4 , 20 kHz LPF)
■
SPEAKER SECTION
Front speaker (L/C/R)
Type 2 way, 2 speaker (Closed)
Woofer 6.5 cm × 1/ch, Cone type
Tweeter 1.6 cm × 1/ch, Dome type
Subwoofer
Type
1 way,
1 speaker (Bass reflex)
Subwoofer 12 cm × 1, Cone type
■
Bluetooth
®
SECTION
Bluetooth
®
system
specification
Bluetooth
®
Ver.4.2
Wireless equipment
classification
Class 2 (2.5 mW)
Supported profiles A2DP, AVRCP
Supported codec AAC, SBC
Frequency band 2.4 GHz band FH-SS
Operating distance
Approx. 10 m Line of
sight
*
1
*
1: Prospective communication distance
Measurement environment:
Temperature 25 °C/ Height 1.0 m
Measure in “Mode1”
■
TERMINALS SECTION
USB
Type A Connector
USB 2.0 High-Speed
DC 5 V 500 mA
USB Mass Storage Class
File system:
FAT16, FAT32, NTFS
Support Memory
Capacity
2 TB (max)
Maximum
number of folders
(albums)
800
Maximum
number of files
(songs)
8000
Ethernet interface
LAN
(100BASE-TX/10BASE-T)
AUX Input Stereo, 3.5 mm Jack
Digital Input
Optical digital input
(Optical terminal)
Format support LPCM
■
Wi-Fi SECTION
Standard IEEE802.11a/b/g/n/ac
Frequency band
2.4 GHz band
5 GHz band
Security
WPA2™,
Mixed mode WPA2™/
WPA™
WPS version Version 2.0
• The WLAN feature of this product shall
exclusively be used inside buildings.
