Technics SA-C600 Basic Owner's Manual

English
11
Connections
(11)
FM antenna connection
FM ANT terminal
Insert the antenna
plug to be connected
all the way in.
Adhesive tape
(not supplied)
FM indoor antenna (supplied)
• Tape the antenna to a wall or column at the
position with the least amount of interference.
• The interference may occur if any electronic
devices are nearby.
Speaker connection
1 Turn the knobs to loosen them, and
insert the core wires into the holes.
2 Tighten the knobs.
Note
• When the connections are completed, pull the
speaker cables lightly to check that they are
connected firmly.
• Be careful not to cross (short-circuit) or reverse
the polarity of the speaker wires as doing so
may damage the amplifier.
DO NOT
• Wire the polarity (+/-) of the terminals correctly.
Not doing so may adversely affect stereo
effects or cause malfunction.
• For details, refer to the operating instructions
of the speakers.
AC mains lead connection
Connect only after all other connections are
completed.
AC IN terminal
To a household AC outlet
• Use only the supplied AC power supply cord.
• Do not connect the AC power supply cord until
all other connections are complete.
• Insert the plugs of the cables to be connected
all the way in.
• Do not bend cables at sharp angles.
• Wireless LAN (Wi-Fi
®
) setting may start when
this unit is turned on. If you stop the Wi-Fi
setting, select “Off” in “Wi-Fi Setup” screen.
Select “Yes” to keep the Wi-Fi setting. ( 13)
Note
• This unit consumes a small amount of AC
power ( 20) even when the unit is in standby
mode. Remove the plug from the main
electrical outlet if you will not be using the unit
for an extended period of time. Place the unit
so the plug can be easily removed.
Note
