13.2 Components Parts List
TOP PREVIOUS NEXT
Ref. No. Part No. Part Name & Description Remarks
P.C.B.
REP3161B-M MAIN P.C.B./TRANSFORMER P.C.B. [M]RTL
REP3020J-S FRONT VCR3 INPUT P.C.B./S-VIDEO P.C.B./HEADPHONES JACK P.C.B./PHONO P.C.B./EARTH
TERMINAL P.C.B./PANEL P.C.B./TONE P.C.B./KEY P.C.B.
[M]RTL
REP3162B-P SURROUND P.C.B./INPUT SELECTOR P.C.B./VOLUME P.C.B./POWER P.C.B./SPEAKER TERMINAL
P.C.B./AC IN/OUT P.C.B.
[M]RTL
RAN0001MM TUNER MODULE P.C.B. [M]RTL
REP2703D-T DTS MODULE P.C.B. [M]RTL
SCREW
SC1701 XYN3+F8 SCREW [M]
INTEGRATED CIRCUITS
IC301 NJM2279D IC VIDEO SELECTOR SW [M]
IC302 NJM2279D IC VIDEO SELECTOR SW [M]
IC351 NJM2296D IC VIDEO SELECTOR [M]
IC401 TC9163AN IC SELECTOR [M]
IC402 NJM4580EDTE1 IC OP AMP [M]
IC403 TC9162AN IC SELECTOR [M]
IC405 NJM4580EDTE1 IC OP AMP [M]
IC406 NJM4580EDTE1 IC OP AMP [M]
IC451 AN6558F IC PHONO EQ AMP [M]
IC501 BA6218 IC MOTOR DRIVER [M]
IC502 NJM4580EDTE1 IC TONE AMP [M]
IC503 NJM4580EDTE1 IC TONE AMP [M]
IC504 NJM4580EDTE1 IC TONE AMP [M]
IC505 NJM4580DD IC TONE AMP [M]
IC506 NJM4580DD IC TONE AMP [M]
IC507 NJM4580DD IC TONE AMP [M]
IC508 NJM4580DD IC TONE AMP [M]
IC601 RSN310R37A-P IC 3 CH HIC
[M]
IC602 RSN310R37A-P IC 3 CH HIC
[M]
IC901 M38B57MCA266 IC SYSTEM CONTROL [M]
IC902 BU2090A IC EXPANDER [M]
IC1001 CS49326-CLR IC AC-3/DTS DECODER [M]
IC1002 C0FBZJ000004 IC DIR/DAC/VOL [M]
IC1003 SN74LV244APW IC LOGIC [M]
IC1004 SN7AHCT244PW IC LOGIC [M]
IC1005 SN74HCU04APW IC LOGIC [M]
IC1006 SNAHC1U04DBV IC SINGLE INVERTER [M]
IC1201 NJM4580EDTE1 IC OP AMP [M]
IC1202 NJM4580EDTE1 IC OP AMP [M]
