Memory devices
The following sections lists the volatile and nonvolatile memory devices in the
instrument.
Volatile memory devices
DDR2_RAM
Type and size 16 x 32 M
Function Microprocessor system memory
User modifiable No
Data input method Written by processor system
Location U82, U32
User accessible No
Process to sanitize Turn off instrument power
Nonvolatile memory devices
Device name Flash
Type and size 8 x 128 M
Type of user information
stored
User data, user settings, user waveforms
User modifiable Yes
Data input method Firmware operations
Location U32
Process to sanitize Refer to the Clear Flash procedure on page 5
AFG1000 Series Declassification and Security 1
