Tektronix AFG3011 User Manual

Operating basics
6. Select Burst as the Run
Mode for both the master
and the slave i
nstrument.
To synchronize two
instruments, you must
stop running
output
signals once before
triggering using the Burst
mode.
7. Select the t
rigger source
of the slave unit.
Push the -more- bezel
button in t
he Burst mode
to display the second
page.
8. Push the S
ource bezel
button to select External.
Confirm that Internal is
selected
in the master
and External is selected
in the slave for Source.
9. This screen shows signal
outputs by master-slave
operation. The top
waveform is the signal of
the master unit.
10. When one meter long
cables are used, the
slave s ignal(s) delays
approximately 40 ns.
11. To make the delay
betw
een the master and
slave 0 (zero), set Delay
of the master unit.
12. The s
creen s hows
waveforms after setting
the delay to the master
uni
t. The top waveform
is master and the two
bottom waveforms are
sla
ves.
76 AFG3000 and AFG3000C Series User Manual
