Instrument interface, front panel, and rear panel
GPIB and Ethern
et setups
Access protection
Select Waveform
The instrument can provide 12 standard waveforms (Sine, Square, Ramp,
Pulse, Sin(
x)/x, Noise, DC, Gaussian, Lorentz, Exponential Rise, Exponential
Decay, and Haversine). The instrument can also provide user-defined arbitrary
waveforms. You can create, edit, and save your custom waveforms.
You can also create modulated waveforms using the Run Mode Modulation
menus. The following table shows the combination of modulation type and the
shape of the output waveform.
AFG3000 and AFG3000C Series User Manual 31
