Tektronix DPO4104 Demo Instruction Manual

Giving Demos of Advanced Tektronix 40 00 Features
Wave Inspector Demo s
Background.
Digital oscilloscope record lengths have gone from 50 0 points in the early 1980 ’s to millions of points today.
The Tektronix 4000 series places emphasis not only on the quantity of record length provided but also on the usa bility of the
data. Imagine trying to find what you are looking for on the Web these days without search engines like Go ogle.
As record lengths have gotten longer, virtually every digital oscilloscope has implemented a zoom model. However, most
zoom mod els are operated with controls b uried in menus or front-pan el controls that a re multiplexed with oth er functions. The
Tektronix 4000 series zoom contro ls are easily accessible on the front panel.
22 Tektronix 4000 Oscilloscope Demo Instruction Manual
