Performance Verification
DC Balance
Performance checks Vertical scale Low limit Test result High limit
1 mV/div
1
-0.3 mV 0.3 mV
100 mV/div
-20mV 20mV
Channel 4 DC Balance,
1MΩ, 250 MHz BW
1V/div
-200 mV 200 mV
1 mV/div
-0.5 mV 0.5 mV
2 mV/div
-0.5 mV 0.5 mV
100 mV/div
-20mV 20mV
Channel 4 DC Balance,
50 Ω,FullBW
1V/div
-200 mV 200 mV
1 mV/div
1
-0.3 mV 0.3 mV
100 mV/div
-20mV 20mV
Channel 4 DC Balance,
1MΩ,FullBW
1V/div
-200 mV 200 mV
1
Immediately after calibration, the specification is -0.2 div to 0.20 div.
For performance verification testing, the specification is -0.3 to 0.3 div.
Performance checks: Bandwidth
Bandwidth at
Channel Impedance Vertical scale V
in-pp
V
bw-pp
Limit
Test result
Gain =
V
bw-pp
/V
in-pp
All models:
1
50 Ω 5 mV/div
≥ 0.707
1
50 Ω 2 mV/div
≥ 0.707
1
50 Ω 1 mV/div
≥ 0.707
1
1MΩ 5 mV/div
≥ 0.707
1
1MΩ 2 mV/div
≥ 0.707
1
1MΩ 1 mV/div
≥ 0.707
2
50 Ω 5 mV/div
≥ 0.707
2
50 Ω 2 mV/div
≥ 0.707
2
50 Ω 1 mV/div
≥ 0.707
2
1MΩ 5 mV/div
≥ 0.707
2
1MΩ 2 mV/div
≥ 0.707
2
1MΩ 1 mV/div
≥ 0.707
DPO4104, DPO4054, DPO4034, MSO4104, MSO 4054, MSO4034:
3
50 Ω 5 mV/div
≥ 0.707
3
50 Ω 2 mV/div
≥ 0.707
3
50 Ω 1 mV/div
≥ 0.707
3
1MΩ 5 mV/div
≥ 0.707
3
1MΩ 2 mV/div
≥ 0.707
3
1MΩ 1 mV/div
≥ 0.707
4
50 Ω 5 mV/div
≥ 0.707
22 MSO4000 and DPO4000 Series Specifications and Performance Verification
