Display specifications
Display type 7 inch TFT Liquid Crystal Display (LCD).
Display Resolution This is the number of individually addressable pixels
800 horizontal by 480 vertical displayed pixels
Format YT and XY
Waveform styles Vectors, variable persistence, and Infinite persistence.
Luminance, typical 300 cd/m
2
, typical.
Contrast ratio and control, typical Available black room contrast ratio, full black to full white. 400 minimum, 500 typical.
Interfaces and output ports specifications
USB Interface 1 High Speed USB2.0 Host and 1 High Speed USB2.0 Device connector are standard in all
models.
Kensington style lock Rear-Panel security slot connects to standard Kensington-style lock
Probe compensator, output
voltage and frequency, typical
The Probe compensator output voltage is in peak-to-peak volts and frequency is in Hertz.
0-5V amplitude +/- 10%, 1 kHz +/- 10%
Data handling characteristics
Retention of front panel settings Front panel settings are stored periodically in memory. The settings are not lost when the
instrument is turned off or if there is a power failure.
Stored waveforms and multiple
front panel settings
Two Channel 1, Channel 2, or Math waveforms can be stored in nonvolatile waveform memory A or
B. One, both, or neither of A or B waveform memories can be displayed. Ten user setups of the
current instrument settings can be saved and restored from nonvolatile memory. Additional storage
is available when an appropriate mass storage device is connected via USB.
Specifications
10 TBS1000C Series Specification and Performance Verification
