Tektronix TDS1002 User Manual

TDS1000/2000-Series Digital Oscilloscope User Manual
127
TDS2CMA Communications Module
This chapter describes how to use the TDS2CMA Communications
Extension Module (optional) with a TDS1000- or TDS2000-series
oscilloscope.The TDS2CMA module adds Centronics, RS-232 and
GPIB communication ports to the oscilloscope. For ordering
information, refer to page 169.
This chapter describes how to do the following tasks:
H Install the exte nsion module
H Set up and test the RS-232 interface
H Set up and test the GPIB interface
H Send screen data to an external device (printer or computer)
Installing and Removing an Extension Module
This section describes how to safely remove and install an extension
module on your oscilloscope.
