Replaceable Parts
TDS1000B and TDS2000B Series Oscilloscope Service Manual
8-- 9
J201
J400
J101
Backlight cable
Power supply
module
Chassis
ground lug
Power supply
ground wire
J1
1
2
3
4
Main channel assembly
Chassis
assembly
Front panel
assembly
Display
assembly
4
Front panel
cable
Display
cable
4
4
5
6
Power supply
cable
7
Figure 8--3: Exploded diagram, power supply module, cables and wires
