Performance Verification
4-8
TDS1000 and TDS2000 S eries Digital Storage Oscilloscopes Service Manual
5. Set the leveled sine wave generator frequency to 10 MHz.
6. Set the leveled sine wave generator output level to approximately 500 mV
p-p
so that the measured amplitude is approximately 500 mV. (The measured
amplitude can fluctuate around 500 mV.)
7. Press SET LEVEL TO 50%. Adjust TRIGGER LEVEL as necessary and
then check that triggering is stable.
8. Set the leveled sine wave generator frequency to
H 40 MHz if you are checking a TDS1001
H 60 MHz if you are checking a TDS1002/2002/TDS2004
H 100 MHz if you are checking a TDS1012/2012/2014
H 200 MHz if you are checking TDS2022/2024.
9. Set the oscilloscope SEC/DIV to 10 ns/div.
10. S et the leveled sine wave generator output level to approximately 750 mV
p-p
so that the measured amplitude is approximately 750 mV. (The measured
amplitude can fluctuate around 750 mV.)
11. Press SET LEVEL TO 50%. Adjust TRIGGER LEVEL as necessary and
then check that triggering is stable.
12. C hange the oscilloscope setup using the following step:
Press menu button Select menu option Select setting
TRIGGER Slope Falling
13. Press SET LEVEL TO 50%. Adjust TRIGGER LEVEL as necessary and
then check that triggering is stable.
14. C hange the oscilloscope setup using the following step:
Press menu button Select menu option Select setting
TRIGGER Slope Rising
15. Disconnect the test setup.
16. R epeat steps 1 through 15 until all input channels have been checked.
