Chapter 1 Installing the Router
1.1 Introduction
The Teldat C+ is a general-purpose IP router, suitable for a wide range of applications (personal, SOHO/SME and
corporate environments). It adapts perfectly to plenty of IP scenarios, providing simultaneous access to Internet for
private LAN users and accommodating teleprocess networks and SNA support.
The Teldat C+ covers the access needs for ADSL and ADS2+ (both over PSTN and ISDN). For local area net-
works (LANs), the routers can incorporate Switch LAN Ethernet and Wireless LAN MINI-PCI Module.
This manual is the installation and device connection guide.
Fig. 1: Teldat C1+: External aspect
Fig. 2: Teldat C8+ /C9+ external power: External aspect
Fig. 3: Teldat C8+ /C9+ internal power: External aspect
1.1.1 Recycling and the Environment
Please do not, under any circumstances, throw away any Teldat C+ routers with normal domestic waste. Ask your
local town hall for information on how to correctly dispose of them in order to protect the environment against e-
waste. Always respect the current laws regarding waste material. Anyone found violating the environmental laws will
be subject to fines and any additional steps established by law.
All the packing materials i.e. the cardboard box, plastic and any other packaging, together with the pieces making up
a Teldat C+ , must be recycled complying with the current active laws regarding recycling materials.
The symbol shown below with a cross over the rubbish container can be seen on the device. This means that, when
a device reaches the end of its life, it must be taken to the official recycling/disposal centers where it must be dis-
posed of in an environmentally responsible manner and separately from normal domestic waste.
1 Installing the Router Teldat S.A.
2 Teldat C+ Router Family
