Tenda HG9 User Manual

PON WAN
This page is used to configure the parameters for PONWAN
Enable VLAN:
VLAN ID:
802.1p_Mark
Channel Mode:
Admin Status:
Connection Type:
MTU:
Enable IGMP-Proxy:
Enable MLD-Proxy:
IP Protocol:
0
INTERNET
IPv4
1500
nas0_0
Enable Disable
Type:
Local IP Address
Remote IP Address
Subnet Mask
IP Unnumbered
Request DNS
Primary DNS Server
Secondary DNS Server
WAN IP Settings:
IPoE
0
Fixed IP DHCP
0.0.0.0
0.0.0.0
255.255.255.0
Enable Disable
Option 2 Access internet over DHCP
Step 1: Log in to the web UI
Step 2: Set up a WAN connection
Refer to Step 1: Log in to the web UI in Option 1 Access internet over PPPoE to log in to
the web UI of the ONT.
➊ Choose WAN > PON WAN.
➋ Tick Enable VLAN.
➌ Enter the VLAN ID provided by ISP.
➍ Set Channel Mode to IPoE.
➎ Set Connection Type to INTERNET.
➏ Click Apply Changes.
➐ Click OK when Change setting successfully is shown on the page.
6

Tenda HG9 Specifications

General

ITU standards	G.984.1, G.984.2, G.984.3, G.984.4
Networking standards	IEEE 802.1Q, IEEE 802.3u, IEEE 802.3z
Transmission distance (max)	20 km
Wi-Fi	Yes
Antennas quantity	2
Antenna gain level (max)	6 dBi
Fiber ports quantity	1
Fiber optic connector	SC
Ethernet LAN (RJ-45) ports	4
Product type	Optical network terminal (ONT)
Product color	White
Power consumption (typical)	18 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	124.9 mm
Width	190 mm
Height	26.5 mm
