Page 10
STEP 6
MOUNT VENT & COOKTOP
A. Remove grease filters and any packing materials from
inside the intake.
B. Set the vent intake into rear of countertop opening.
Carefully lower it into position so that the flanges on
the rear sides and edges fully support the unit hanging
from the countertop.
C Loosely fasten lower support legs to vent. Hold the
unit against the rear of the countertop opening, and,
with it in vertical position, slide the brackets down to
meet the bottom of cabinet and fasten to cabinet with
hardware provided. Then tighten brackets on vent.
Refer to Figure 1. Fasten support legs to cabinet floor.
D. Place the cooktop in countertop opening with the rear
edge of cooktop overlapping the front edge of the vent.
Make sure rear edge of cooktop does not bind
against front of snorkel. Follow the manufacturer's
installation instructions for installing the cooktop.
STEP 4
INSTALL DUCTWORK
(REMOTE BLOWER - if used)
A. Install the ductwork and remote blower (if used) in
accordance with the ductwork routing plan developed
in Step 1.
B. Make sure that the installation complies with all instal-
lation guidelines in Table 2. Check the opening where
ducting passes through the outside wall or roof has
been properly flashed and sealed to prevent leakage.
C. If using integral blower model VTN600CVR proceed
to Step 5.
D. If using remote blower model VTR600R
or VTR1000Q,
refer to Installation Instructions with that model.
Check your local building codes for proper method of
installation. In the U.S., if there are no applicable local
codes, this unit should be installed in accordance with the
National Electric Code ANSI/NFPA No. 70, Current Issue.
(In Canada, installation must be in accordance with the CAN
1-B149.1 and .2 - Installation Codes for Gas Burning Appli-
ances and/ or local codes).
This appliance is factory equipped with a power supply cord
having a three-prong grounding plug (with polarized paral-
lel blades). IT MUST BE PLUGGED INTO A MATING
GROUNDING TYPE RECEPTACLE, CONNECTED TO
A CORRECTLY POLARIZED 120 VOLT CIRCUIT.
The receptacle should be located under the countertop so
that the 30 inch long power cord from the vent will reach it.
See Figure 9. The cord should be routed beneath the appli-
ance and away from heat generated by the cooktop. Access
should not be obstructed by blower, cabinet work, ductwork
or electrical/gas utilities for the cooktop. All power for the
vent system (including the remote blower, if used) is sup-
plied via the cord to the intake unit. The outlet can usually
be extended from another kitchen outlet or have its own
circuit from the main service panel.
Do not plug vent cord into receptacle until Step 8.
