＜General Safety Information＞
Please read this manual and follow its instructions carefully. The following safety symbols and signal words are
used throughout the manual to alert you to possible hazardous situations.
＜Installation＞
1. Location: The TOCS 4.3” LCD Display should be located at least 300 mm (12”) from a magnetic compass.
2. Disconnect the battery.
3. Remove the Bezel from the display.
4. Cut a 111mm (4.371") diameter hole in the dash
allowing a clearance of behind 80mm (3”) for wires.
5. Thread the cables through the hole and plug the connector.
6. Mount the display from the front. Use the supplied screws and washers and tighten.
7. Install the bezel.
Disconnect battery during installation.
Use stranded, insulated wire not smaller than 18 AWG. Be certain wire insulation is not in danger of melting from engine or
exhaust heat or interfering with moving mechanical parts.
