7) The brightness (sun) sensor requires to disable the controls of the rain and wind
sensors for the outputs M5 and M6 by means of the “DIP-switch” No.6, which has to
be on “OFF” position. The brightness sensor can have two opposite functions;
To select the wished function, it is necessary to act on the “DIP- switch” No.4 placed
on the electronic card programming it as follows:
8) By programming the “DIP-switch” No.5, it is possible to modify the type of control.
When the “DIP-switch” is programmed on "AUTOMATIC" mode, the control by
manual push-button, radio control or remote control operates on a step by step
system basis (open, stop, close, stop, etc.). When it is programmed on "MAN
PRESENT" mode, only the manual push-button is enabled. This choice of indirect
safety excludes consequently all commands coming from radio control and remote
control.
To vary this function, set the following programming:
15
TF21/44R/T
Tab.4
Tab.5
ON
OFF
OFF
ON
INSTALLATION AND USE INSTRUCTIONS
INSTALLATION -5
Function
Position of DIP-switch No.6
If the OPEN (+ light) threshold is exceeded
If the CLOSE (+ light) threshold is exceeded
Function
Position of DIP-switch No.5
Automatic
Man present
VER.1.0
REV.07.04
