5.7- PROGRAMMING OF REMOTE ELECTRONIC CONTROL MOD. F33.
THIS CHAPTER DESCRIBES THE PROGRAMMING OF THE "433 MHz RADIO CONTROL"
MOD. F33.
The green LED DL1 blinks every time the receiver within the feeding unit receives a
valid code from the radio control, even if it has not been programmed. In this way, it is
possible to have more information on the possible malfunctions of the system.
Given that the used coding is with variable code, each remote control sends a signal
that is different from all the others. Therefore, the receiver must be able to recognise
the enabled remote controls.
To each push-button corresponds an M output:
To output M3 corresponds the push-button on the top left side
To output M4 corresponds the push-button on the top right side
To output M5 corresponds the push-button on the bottom left side
To output M6 corresponds the push-button on the bottom right side
16
TF21/44R/T
INSTALLATION AND USE INSTRUCTIONS
5- INSTALLATION
VER.1.0
REV.07.04
