13
PARTS LIST
TROT-MOP ASSEMBLY (90679)
ITEM
PART
NO QTY DESCRIPTION
1 696 1 Washer-Plain #10
2 851 2 Washer-Plain 1/4"
3 1577 11 Washer-Lock (H/S) 5/16 (Regular)
4 1979 1 Screw-Rnd.Hd. 1/4-20 x 2"
5 2053 1 Screw-Rnd.Hd. 1/4-20 x 7/8"
6 2109 7 Screw-Hex.Hd. 5/16-18 x 3/4"
7 3264 2 Wheel-3" Dia.
8 7132 2 Washer-Spring (3-Wave) 3/8"
9 7719 9 Nut-Hex. 5/16-18
10 10694 2 Nut-Hex.Jam 1/4-20
11 12716 2 Nut-Acorn (Non-Standard) 5/16-18
12 12957 2 Washer-Plain 1/2"
13 14142 2 Washer-Plain 1/4"
14 16031 2 Screw-Hex.Hd. Cap 5/16-18 x 1-1/2"
15 16202 1 Spring-Tension
16 17130 3 Nut-Acorn, Lock(P/T) 1/4-20
17 17400 2 Spacer-1/4" Dia.
18 18136 1 Channel-Outer (30" Squeegee)
19 30227 2 Pin-Cotter (Ext.Prong)-5/64 x 1/2" STL ZP
20 30226 2 Pin-Clevis .320 Dia / 1-1/4" Long
21 18400 2 Wheel-1-5/8" Dia.
22 18518 2 Spacer-5/16" Dia.
23 18519 2 Plate-Back Up Wheel Bracket Spacer
24 18523 2 Plate-Handle Pivot
25 18528 2 Weldment-Squeegee Lift Arm
26 18529 1 Assembly-Handle and Grip (TM-4000)
27 18663 1 Retainer-30" Squeegee Blade
28 18680 2 Screw-Flt.Cap. 1/4-20 x 2-1/4" (SS)
29 18681 2 Screw-Flt.Cap. 5/16-18 x 1-3/4" (SS)
30 18709 2 Squeegee Blade Assy. Set-30"(2 Blades)
31 18733 2 Bracket-Back Up Wheel Mounting
32 17524 1 Hose Assy.-Trop Mop (Hose and Sleeve)
33 17502 1 Label-"Trot Mop"
34 16581 4 Washer-Plain 1/2" I D
To Next Page
