Toro 01007 User Manual

3
Specifications
General Specifications
Reel Drive
Reel driven by wheels 75T ring gear to 10T pinion through 14T disengaging idler
gear.
Reduction, Reel to
Wheels
7.5:1
Welded Reel
Medium carbon steel, induction hardened blades are welded to seven steel spiders
which are mounted on a 1–1/2” (38 mm) diameter shaft. Tapered roller bearings
support reel shaft, and an adjusting nut compensates for bearing wear. Diameter of
11 blade reel is 7 inches (17.8 cm). 5 and 7 blade reels are 8” inches (20.3 cm).
Bedknife & Bedbar
Single edge high carbon steel knife attached to a fabricated steel bar; single screw
adjustment on adjustable rod ends.
Bedknife to Reel
Adjustment
Bedknife adjusts against reel, with positive adjustment control knob located at
center of bedbar. Adjustment knob contains detent with .001 inch (0.0254 mm)
movement of bedknife for each indexed position. Pivot point at top of bedbar is
greasable.
Wheels and Tires
16” (0.406 m) diameter pneumatic wheels with tire and tube, studded tread,
stamped steel wheel and cast iron hubs; 16” (0.406 m) diameter semi pneumatic
tires with stamped steel wheels and cast iron hubs; 16” (0.4(06 m) diameter cast
iron wheels – one piece construction; 16” (0.406 m) diameter low profile
semi–pneumatic tires with stamped steel wheels and cast iron hubs; 18” (0.457 m)
semi–pneumatic tires with stamped steel wheels and cast iron hubs.
Differential Disengaging over–running idler gear in gear train.
Width of Cut 30” (0.762 m)
Height of Cut
11 Blade – .38 inches (9.5 mm) to 1.25 inches (32 mm) with 16” (0.406 m) dia.
wheel.
7 Blade – .75 inches (19 mm) to 1.75 inches (45 mm) with 16” (0.406 m) dia. wheel.
5 Blade – 1.25 inches (32 mm) to 2.25 inches (57 mm) with 16” (0.406 m) dia.
wheel
5 Blade – 2.00 inches (50 mm) to 3.00 inches (76 mm) with 18” (0.457 m) dia.
wheel
All adjustment are made in .040 inch increments.
Frequency of Clip
11 Blade w/16” wheels – .58” clip (68 cuts per meter)
7 Blade w/16” wheels – .91” clip (43 cuts per meter)
5 Blade w/16’ wheels – 1.28” clip (31 cuts per meter)
5 Blade w/18” wheels – 1.51” clip (26 cuts per meter)
Chassis
Ribbed cast iron gear cases with tubular cross members. Front cross member
provides easy attachment for the mower to the Reelmaster Universal and
Reelmaster Transport frames.
Roller
3–1/2” (88.9 mm) O.D. Iron pipe running on taper bearings double lip oil seal with
wear sleeves. Grease fittings provided.
