ProcedureDescription
Qty.
Use
6
Nopartsrequired
–
Checktheoperationoftheattachment
lift.
7
Nopartsrequired
–
Adjustthespeedandthetracking.
8
Nopartsrequired
–
Installthestopplates.
1
InstallingtheLiftBrackets
Partsneededforthisprocedure:
1
Liftbracket(left-hand)
1
Liftbracket(right-hand)
2
Locknut(1/2inch)
Procedure
1.Removethetopnutsecuringtheleft-handside
oftherolloverprotectionsystem(ROPS)tothe
machineframe(Figure1).
Note:Retaintheboltandthespringwasher
forinstallation.
g024660
Figure1
Left-handsideshown
2.Aligntheleft-handliftbrackettothemachine
frame(Figure2).
g024661
Figure2
Left-handsideshown
1.Bolt(existing)3.Liftbracket
2.Springwasher(existing)
4.1/2inchlocknut
3.Securetheexistingboltandspringwasherwith
anew1/2inchlocknut,andtorquethelocknutto
102to108N-m(75to80ft-lb).
Important:Ensurethatthespringwasheris
positionedsothattheconvexsidefacesthe
boltheadasshowninFigure3.
g023904
Figure3
4.Repeattheprocedurefortheright-handsideof
themachine.
