Toro 20093 User Manual

Setup
Important:Removeanddiscardtheprotective
plasticsheetthatcoverstheengine.
1.InstallingtheBladeControl
Bar
Procedure
Installthebladecontrolbarintotheupperhandle
(Figure3).
Figure3
2.AssemblingandUnfolding
theHandle
Procedure
Assemblingandunfoldingthehandle
improperlycandamagethecables,causingan
unsafeoperatingcondition.
•Donotdamagethecableswhenassembling
andunfoldingthehandle.
•Ensurethatthecablesareroutedtothe
outsideofthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Raisetherearofthemowerhousingtoitshighest
cuttingheightsettingbymovingthe2rearcutting
heightleversallthewayforward.RefertoAdjusting
theCuttingHeightintheOperationsection.
2.Attachthehandleendstothemowerhousingwith
2washersand2handlebolts(Figure4),butdonot
tightenthehandlebolts.
Figure4
1.Washer3.Handleend
2.Handlebolt
Important:Routethecablestothe outside of
thehandle(Figure4).
3.Rotatethehandlerearward(Figure5).
Figure5
4.Lockthehandleatyourdesiredheight.Referto
AdjustingtheHandleHeightintheOperation
section.
5
