Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Bolt(1/2x1-1/2inches)
4
Curvedwasher
2
Spacer
2
1
Locknut(1/2inch)
4
Installthehandle.
2
SAE30detergentoilwithanAPIservice
classicationofSH,SJ,SL,orhigher
(notsuppliedwiththemower).
20oz.
(0.55l)
Filltheenginewithoil.
3
Nopartsrequired
–
Installthemulchplugorgrassbag.
1
InstallingtheHandle
Partsneededforthisprocedure:
4
Bolt(1/2x1-1/2inches)
2
Curvedwasher
2
Spacer
4
Locknut(1/2inch)
Procedure
1.Removethetwoscrewsthatholdthebackcoverin
placeandremovethebackcover(Figure3).
Figure3
2.Attachthehandletothemowerhousing(Figure4)
usingthe4bolts,4locknuts,2spacers,and2curved
washersintheloosepartsbag.
Figure4
1.Bolt(1/2x1-1/2inches)
(4)
3.Spacer(2)
2.Curvedwasher(2)4.Locknut(1/2inch)(4)
Note:Youcansetthehandleheightinoneoftwo
positions(Figure5).Setthehandletoaheightthatis
comfortableforyou.
7
