Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Handle1
Hex-head-angebolt(5/16x1-1/2
inches)
2
Carriagebolt(5/16x1-1/2inches)
2
1
Flangenut(5/16inch)
4
Installthehandle.
2
Nopartsrequired
–
Installthestarterrope.
3
Nopartsrequired
–
Fillthecrankcasewithoil.
4
Nopartsrequired
–
Adjusttheself-propeldrive.
5
Nopartsrequired
–
Assemblethegrassbag.
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
1
InstallingtheHandle
Partsneededforthisprocedure:
1Handle
2
Hex-head-angebolt(5/16x1-1/2inches)
2
Carriagebolt(5/16x1-1/2inches)
4
Flangenut(5/16inch)
Procedure
1.Removethecableguardfromthehandle(Figure3)by
removingthe2carriageboltsand2locknutsthathold
thecableguardtothehandle.
Figure3
1.Cableguard4.Flangenut—5/16inch(2)
2.Locknut(2)5.Hex-head-ange
bolt—5/16x1-1/2inches
(2)
3.Carriagebolt—1/4x1-1/2
inches(2)
Note:Savetheguard,thecarriagebolts,andthe
locknutssothatyoucaninstallitontothehandlelater
inthisprocedure.
2.Installthehandleendsontothemowerhousingwith
2hex-head-angebolts(5/16x1-1/2inches)and2
angenuts(5/16inch)asshowninFigure3.
7
