Lubrication
GreasingtheTractionUnit
ServiceInterval:Beforeeachuseordaily(Grease
immediatelyaftereverywashing.)
GreaseType:General-purposegrease.
1.Lowertheloaderarmsandstoptheengine.Remove
thekey.
2.Cleanthegreasettingswitharag.
3.Connectagreaseguntoeachtting(Figure30and
Figure31).
Figure30
Figure31
4.Pumpgreaseintothettingsuntilgreasebeginsto
oozeoutofthebearings(approximately3pumps).
5.Wipeupanyexcessgrease.
EngineMaintenance
ServicingtheAirCleaner
ServiceInterval:Beforeeachuseordaily—Checkthe
airlterserviceindicator.
Every25hours—Removeaircleaner
cover,cleanoutdebris,andcheckthe
airlterserviceindicator.
Every600hours—Replacethesafety
airlter.
ServicingtheAirCleanerCoverand
Body
Important:Servicetheaircleanerlteronly
whentheserviceindicatorshowsred(Figure32).
Changingtheairlterbeforeitisnecessaryonly
increasesthechanceofdirtenteringtheengine
whenthelterisremoved.
1.Lowertheloaderarms,stoptheengine,andremove
thekey.
2.Openthehood.
3.Checktheaircleanerbodyfordamagewhichcould
causeanairleak..Checkthewholeintakesystem
forleaks,damage,orloosehoseclamps.Replaceof
repairanddamagedcomponents.
4.Releasethelatchesontheaircleanerandpulltheair
cleanercoveroffoftheaircleanerbody(Figure32).
Important:Donotremovetheairlters.
G009695
12345
76
Figure32
1.Airlterserviceindicator.
5.Aircleanercover
2.Airlterbody
6.Latches
3.Safetylter
7.Dustcap
4.Primarylter
5.Squeezethedustcapsidestoopenitandknockthe
dustout.
6.Cleantheinsideoftheaircleanercoverwith
compressedair.
7.Checktheairlterserviceindicator.
