Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Nopartsrequired
–
Unfoldthehandle.
Dischargechute1
Chutehandle
1
Phillipsheadbolts3
Washers3
2
Locknuts3
Installthedischargechute.
1
UnfoldingtheHandle
NoPartsRequired
Procedure
1.Loosenthehandleknobs,pulloutthe“U”-shaped
handlelocksuntilyoucanmovethehandlefreely,and
rotatethehandletotheoperatingposition(Figure4).
G016242
Figure4
1.“U”-shapedhandlelock(2)
2.Handleknobs
2.Inserttheendofthe“U”-shapedhandlelockintothe
openholeinthehandleandtightenthehandleknobs
untiltheyaresnug(Figure5).
Figure5
Important:Ensurethatyoudonotpinchorkink
thecontrolcable(Figure6).
Figure6
1.Controlcable
5
