Toro 38812 User Manual

5.Rotatethelowerlinkarmfullydownward(clockwise)
(Figure6).
Figure6
6.Pushdownonthespeedcontrolrodandinsertthe
trunnionintotheholeinthespeedselectorlever
(Figure5).
Note:Ifthetrunniondoesnottintothehole
whenyouliftuponthespeedcontrolrod,rotatethe
trunnionupwardordownwardonthespeedcontrol
roduntilitts.
7.Securethetrunnionandupperendofthespeedcontrol
rodwiththeouterwasherandahairpincotteryou
previouslyremoved.
Note:Foreasierinstallation,lookdownthroughthe
openinginthespeedselector(
Figure7).
Figure7
1.Speedselector
3
InstallingtheChute
Partsneededforthisprocedure:
2Nut
2Bolt
Procedure
1.Placethechuteontheframeandthealignthedischarge
chutemounttothechutesupport.
g019013
1
2
Figure8
1.Bolt2.Nut
2.Securethedischargechutemountusing2boltsand
2nuts.
9
