Toro 500 EFI User Manual

39
To adjust the spring force on the these
shock absorbers, rotate the pre-load
adjustment sleeve with a suitable spanner
wrench until desired spring tension is
achieved.
PR015
On the 700, the rear shock absorber has a
spring force adjustment nut with an
infinite adjustment from softest to most
firm. If the spring action is too soft or too
stiff, adjust the nut using an appropriate
spanner as illustrated.
HDX085A
 NOTE: Before attempting to
adjust suspension, clean dirt and
debris from the sleeve and remove
load from the suspension; then use
the spanner wrench to adjust the
sleeve to the desired position.
General Lubrication
Cables
None of the cables require lubrication;
however, it is advisable to lubricate the
ends of the cables periodically with a
good cable lubricant.
Cargo Box Latches
Periodically apply a light coat of grease
to the latches and pins. Do not over
grease.
Engine/Transmission Oil
and Filter
 NOTE: Refer to the recommended
oil viscosity chart (on page 34) in
this manual for the proper engine oil.
Change the engine oil and oil filter at the
scheduled intervals. The engine should
always be warm when the oil is changed
so the oil will drain easily and completely.
1. Park the vehicle on level ground.
2. Remove the seat; then remove the
backrest and seat base.
3.
Loosen the oil fill cap using a 27 mm
socket (700) or oil level stick (500).
Be careful not to allow contaminants
to enter the opening.
HDX042A
HDX234A
Position
Spring
Force
Setting Load
1
Stronger
Soft
Stiff
Light
Heavy
2
3
4
5
700
500
