Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Auxiliaryhandle1
Latch1
1
Brace1
Installtheauxiliaryhandle.
Guard
1
2
Phillipsscrew1
Installtheguard.
3
Edgeguard1Installtheedgeguard.
4
Nopartsrequired
–
Adjustthetrimmerheightandthebase
position.
1
InstallingtheAuxiliary
Handle
Partsneededforthisprocedure:
1Auxiliaryhandle
1Latch
1Brace
1.Positiontheauxiliaryhandleontheshaftofthetrimmerwith
thesmoothsurfacefacingyou(Figure1).
g017277
Figure1
1.Auxiliaryhandle3.Brace
2.Latch
2.Slidethebraceintotheauxiliaryhandlesothatthebrace
restsinthegroovealongtheshaft(Figure1).
3.Slidethelatchfromtheleftthroughthehandleandbrace,
andtightenthelatchscrewwithaPhillipsscrewdriver
(Figure1).
4
