3
3351-953
Assembly
Assembling the Blower
1.
3.
2.
Important: You must install the blower tube before installing the inlet cover because the inlet cover hooks onto
the blower tube. The blower will not run unless the bottom inlet cover is locked in place.
Converting from Blower to
Vacuum
1.
m--5112
Caution
The impeller rotates for a few seconds after you
turn off the blower and can cut or injure fingers.
Do not remove the bottom inlet cover when the
motor is running or when the unit is plugged into
a power outlet.
2.
m--5113
3.
m --5122
Note: Ensure that you line up the arrows.
To Next Page
