13
Attaching the Grass Deflector
Attaching the grass deector differs depending on the type
of trimmer: curved shaft or straight shaft.
WARNING:
The line cut-off blade on the grass deector
is sharp. Avoid contact with the blade. Failure
to avoid contact can result in serious personal
injury.
WARNING:
Always attach the grass deector prior to
operating trimmer. Failure to attach the grass
deector may result in debris being thrown at
the operator and result in serious injury.
To Attach the Curved Shaft Grass Deflector
Model No. 51954
See Figure 4.
Follow these steps to attach the curved shaft grass deector.
1. Remove the hex head cap screw, at washer, lock
washer, and wing nut from the grass deector.
2. Press the grass deector onto the bottom of the curved
shaft as shown.
3. Insert the hex head cap screw through the grass deec-
tor bracket.
4. Place the at washer and lock washer on the hex head
cap screw.
5. Place the wing nut on the hex head cap screw and turn
clockwise to secure.
Figure 5
To Attach the Straight Shaft Grass Deflector
Model No. 51974
See Figure 5.
Follow these steps to attach the straight shaft grass deector.
1. Remove the wing bolt from the grass deector.
2. Insert the tab on the mounting bracket in the slot on the
grass deector.
3. Align the screw hole in the mounting bracket with the
screw hole in the grass deector.
4. Insert the wing bolt through the mounting bracket and
into the grass deector.
5. Tighten the wing bolt securely.
Assembly
Straight Shaft
Grass Deflector
Tab
Slot
Figure 4
Curved Shaft
Grass Deflector
Wing Nut
Line
Cutting
Blade
Lock
Washer
Hex Head
Cap Screw
Flat
Washer
Bracket
Wing Bolt
