Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Knobnut4
Curvedwasher
4
Saddlebolt
4
Middlehandlebar1
Upperlefthandlebar
1
1
Upperrighthandlebar1
Assemblethehandle.
2
Nopartsrequired
–
Rotatethedragstake.
1
AssemblingtheHandle
Partsneededforthisprocedure:
4Knobnut
4
Curvedwasher
4
Saddlebolt
1Middlehandlebar
1
Upperlefthandlebar
1Upperrighthandlebar
Procedure
1.Parkthemachineonalevelsurface.
2.Setthewheelstothelowestposition;Adjusting
theWheels(page12).
3.Attachthemiddlehandlebartothelower
handlebar.
Note:Youcaninstallitintheupperorlower
holes,dependingonheightpreference.
Important:Donotovertightentheknob
nuts.
g334211
Figure3
1.Middlehandle
4.Curvedwasher(2)
2.Lowerhandle
5.Saddlebolt(2)
3.Knobnut(2)
4.Attachtheupperrightandupperlefthandlebars
tothemiddlehandlebar.
Important:Donotovertightentheknob
nuts.
5
