18
2
1
m–6418
Figure 14
1. Position for operating the
machine
2. Position for pushing the
machine
To Operate the Machine
Push the two bypass levers towards the inside and then pull
them rearward (Fig. 14).
Note: The machine will not drive unless the bypass levers
are pushed in and then to the outside.
Adjusting the Footrest
The footrest can be adjusted forward or backward for
maximum operator comfort.
1. Lift up the footrest and place the rods in the same hole
positions (Fig. 15).
m–6423
1
3
2
3
Figure 15
1. Footrest
2. Rod
3. Hole positions
Removing and Installing the
Engine Hood
1. To remove the hood, loosen the knobs and then pull the
hood back and up (Fig. 16).
2
3
m–6424
Figure 16
1. Engine hood 2. Knob
2. To install the hood, put the hooks into the slots and slide
forward (Fig. 17).
3. Install the knobs into the engine hood (Fig. 16).
