Toro 74399 User Manual

G005078
1
2
3
3
4
5
1
2
3
3
4
5
Figure58
MowerDeckswith2Blades
1.Idlerpulley
4.Spring
2.Mowerbelt5.Enginepulley
3.Outsidepulley
G005191
1
2
3
3
4
5
Figure59
MowerDeckswith3Blades
1.Idlerpulley
4.Spring
2.Mowerbelt5.Enginepulley
3.Outsidepulley
6.Routethenewbeltaroundtheenginepulleyand
mowerpulleys(Figure59).
7.Pulltheidlerpulleyinthedirectionshownin
Figure59androutethebeltontotheidlerpulley
(Figure59).
8.Installthebeltcoversovertheoutsidespindles.
InstallingtheMower
1.Parkthemachineonalevelsurfaceanddisengage
thebladecontrolswitch.
2.Movethemotioncontrolleversoutwardtothe
parkposition,stoptheengine,removethekey,and
waitforallmovingpartstostopbeforeleavingthe
operatingposition.
3.Slidethemowerunderthemachine.
4.Lowertheheight-of-cutlevertothelowestposition.
5.Lifttherearofthemowerdeckandguidethehanger
bracketsovertherearliftrod(Figure57).
6.Attachthefrontsupportrodtothemowerdeckwith
theclevispinandhairpincotter(Figure56).
7.Installthemowerbeltontotheenginepulley;refer
toReplacingtheMowerBelt.
ReplacingtheGrassDeector
ServiceInterval:Beforeeachuseordaily—Inspectthe
grassdeectorfordamage
Anuncovereddischargeopeningcouldallow
thelawnmowertothrowobjectsinthe
operator’sorbystander’sdirectionandresult
inseriousinjury.Also,contactwiththeblade
couldoccur.
Neveroperatethemachinewithoutgrass
deector,dischargecoverorgrasscollection
systeminplace.
Inspectthegrassdeectorfordamagebeforeeachuse.
Replaceanydamagedpartsbeforeuse.
1.LocateitemsshowninFigure60.
43
