Note:Retainallfasteners.

WARNING

Incorrectbattery-cableroutingcould

damagethemachineandcablescausing

sparks.Sparkscancausethebattery

gassestoexplode,resultinginpersonal

injury.

•Alwaysdisconnectthenegative

(black)batterycablebefore

disconnectingthepositive(red)

cable.

•Alwaysconnectthepositive(red)

batterycablebeforeconnectingthe

negative(black)cable.

5.Slidetherubbercoverupthepositive(red)

cable.

6.Disconnectthepositive(red)cablefromthe

batterypost(Figure40).

Note:Retainallfasteners.

7.Removethebatteryhold-downandliftthe

batteryfromthebatterytray(Figure40).

g005072

Figure40

1.Battery

5.Negative(–)batterypost

2.Positive(+)batterypost

6.Wingnut,washer,andbolt

3.Bolt,washer,andnut7.Batteryhold-down

4.Terminalboot

ChargingtheBattery

ServiceInterval:Beforestorage—Chargethebattery

anddisconnectthebatterycables.

1.Removethebatteryfromthechassis;referto

RemovingtheBattery(page33).

2.Chargethebatteryforaminimumof1hourat

6to10A.

Note:Donotoverchargethebattery.

3.Whenthebatteryisfullycharged,unplug

thechargerfromtheelectricaloutlet,then

disconnectthechargerleadsfromthebattery

posts(Figure41).

g000538

Figure41

1.Positive(+)batterypost3.Red(+)chargerlead

2.Negative(–)batterypost4.Black(–)chargerlead

InstallingtheBattery

1.Positionthebatteryinthetray(Figure40).

2.Usingthefastenerspreviouslyremoved,install

thepositive(red)batterycabletothepositive

(+)batteryterminal.

3.Usingthefastenerspreviouslyremoved,install

thenegativebatterycabletothenegative(-)

batteryterminal.

4.Slidetheredterminalbootontothepositive

(red)batterypost.

5.Securethebatterywiththehold-down(Figure

40).

6.Lowertheseat.

34

Table of Contents

Questions and Answers:

J
Jacob GriffithAug 12, 2025
Why does my Toro 74721 Lawn Mower engine not start, start hard, or fail to keep running?
- J
  Jesus GatesAug 13, 2025
  Several factors can cause this issue. The fuel tank might be empty, so refill it. The air cleaner could be dirty, requiring cleaning or replacement. Check if the spark plug wire(s) is loose or disconnected and install the wire(s) on the spark plug. A spark plug(s) may be pitted, fouled, or have an incorrect gap, so install a new, correctly gapped spark plug(s). The fuel filter may be dirty, so replace it. The oil level in the crankcase might be low, so add oil to the crankcase. Finally, ensure that you are using the correct fuel type; if not, drain the tank and replace the fuel with the proper type.
C
christopher57Aug 16, 2025
What to do if the blades do not rotate on my Toro 74721?
- E
  Edward CarpenterAug 17, 2025
  If the blades on your Toro Lawn Mower aren't rotating, it could be due to a worn, loose, or broken drive belt, so install a new drive belt. Alternatively, the drive belt might be off the pulley, so install the drive belt and check the adjusting shafts and belt guides for the correct position. Also, the mower belt could be worn, loose, or broken, so install a new mower belt.
S
Sean MartinAug 20, 2025
What to do if my Toro 74721 Lawn Mower engine overheats?
- E
  Erin AndrewsAug 20, 2025
  If your Toro Lawn Mower engine is overheating, several factors could be the cause. First, the engine load might be excessive, so reduce the ground speed. Second, the oil level in the crankcase might be low, so add oil to the crankcase. Third, check the cooling fins and air passages under the engine blower housing for obstructions and remove them. Fourth, a dirty air cleaner can cause overheating, so clean or replace the air-cleaner element.

Toro 74721 Specifications

General

Transmission	Hydrostatic
Power Source	Gasoline
Starter Type	Electric
Deck Material	Steel
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge Capability	Yes
