Toro Greensmaster 3050 User Manual

11
Setup
Note: Determine the left and right sides of the machine from the normal operating position.
Loose Parts
Description Qty. Use
Seat
Nut, 5/16 in.
Seat cover
1
4
1
Mounting the seat slide and seat cover to the
seat base
Wheel assembly
Rear spindle spacer
1
2
Mounting the rear wheel
Capscrew, 1/2 x 3/4 in.
Washer, 1/2 in.
1
1
Securing the steering arm
Cover
Socket head screw, 1/4 x 3/4 in.
Locknut, 1/4 in.
Washer, 1/4 in.
Self tapping screw
1
1
1
1
2
Mounting the cover
Capscrew, 1/4 x 5/8 in.
Nut, 1/4 in.
2
2
Securing the battery cables to the battery
Gauge bar
Machine screw, #10 x 7/8 in.
Jam nut, #10 in.
1
1
1
Setting the height of cut
Grass basket 3 Mounts to the pull frame
Ignition keys 2
Service decal 11
Affix the appropriate language decal over
English decal 106–9071.
Parts Catalog
Noise certificate
Pre-delivery sheet
Certificate of compliance
1
1
1
1
Operator video 1 Watch before operating the machine.
Operator’s Manual (traction unit)
Engine manual
2
1
Read before operating the machine.
Note: Mounting fasteners for the Greensmaster 3050 cutting unit are included with the cutting units.
