GEAR DRIVE SYSTEM
5-46 GT Series Tractors Service Manual
5
6. Inspect the bearings. Replace if worn or damaged.
7. Insert 2 bearings into the bearing cup (Fig. 601).
9. Install 3 bolts and nuts to secure the bearing cup
assembly to the bracket (Fig. 603).
Fig 601 PICT-7693a
Fig 603 PICT-7688a
10. With the pulley secure in a vise, position the bracket
assembly onto the pulley (Fig. 604).
8. Position the bearing cup assembly onto the bracket
(Fig. 602).
Fig 604 PICT-7686a
Fig 602 PICT-7695a
