Toro Multi Pro 5800 Installation

1
InstalltheCenterBoom
BracketsandCover
Partsneededforthisprocedure:
2
Centerboombracket
2Boommountplate
4U-nut
2
Hexheadscrew,3/8x1-1/4inch
1
Model/serialnumberdecal
1
Regulatorydecal(119-4986)
2
Flangenut(3/8inch)
2Washerplate
4
Hexheadscrew,5/16x1-1/4inch
Procedure
1.Attachthemodel/serialnumberdecalandthe
regulatorydecaltooneofthecenterboombracketsas
showninFigure1.
Note:Beforeapplyingthedecals,cleanthedecalarea
andensurethatitisfreeofdirt,grease,orotherforeign
material.
2.Installeachofthe2centerbracketsandboommount
platestothecenterboomusing2hexheadscrews(3/8
x1-1/4inch)and2angenuts(3/8inch)asshown
inFigure1.
Note:Whenmountingthekittoasprayer,usethe
holesinthecenterbrackettoattachthekittotheunit.
WhenmountingthekittoaWorkman,usetheholesin
theboommountplatetoattachthekittotheunit.
3.Installthecentercoverassemblytothecenterboom
bracketsusing4U-nuts2washerplates,and4hexhead
screws(5/16x1-1/4inch)asshowninFigure1.
2
InstalltheWingBoomCovers
Partsneededforthisprocedure:
2Wingboomcover
16Washerplate
12U-nut
12
Hexheadscrew,5/16x1-1/4inch
Procedure
1.Orientthespraynozzlesonbothwingboomsstraight
downwardsothatitcantintheholesofthewing
boomcovers.
2.Installoneofthewingboomcovers(Figure1)using8
washerplates,6hexheadscrews(5/16x1-1/4inch),
and6U-nuts.
3.Repeatstep2toinstalltheotherwingboomcover.
3
InstallingtheDrainValve
MountBracket
Partsneededforthisprocedure:
1Drainvalvemountbracket
2
Carriagescrew(3/8x1-1/4inch)
2
Flangenut(5/16inch)
Procedure
1.Installthedrainvalvemountbracketontothemachine
with2carriagescrewsand2angenuts(5/16inch)as
showninFigure1.
2.Movethedrainvalvefromitsexistingpositionand
installitontothemountingbracket(Figure1)usingthe
existinglynchpinandlanyard.
2
