Figure7
1.Wheelclutchlever
3.Removethenutandwasherfromthehandle,attach
thecableclamponthecabletothehandle,installthe
washerandthenut,andhandtightenthenut(Figure8).
Figure8
1.Cableclamp(2)
Important:Ensurethatthecurvedsideofthe
cableclampisagainstthehandleandthatthe
cableisroutedbelowtheclampbolt.Thecable
mustbeinastraightlinefromthecableclamp
tothepointwhereitattachestothewheelclutch
lever.
4.Pullthecablejacketdowngentlyuntilthewheelclutch
leverisdownandtheslackisoutofthecable,then
tightenthecableclampnutsecurely(Figure9).
Figure9
5.Squeezetheleverfully,thencheckthegapbetweenthe
bottomofthehandleandthewheelclutchleverend
(Figure10).
Figure10
Note:Thegapshouldbeapproximatelythethickness
ofapencil(1/4inchor6mm).Ifitisgreater,loosen
thecableclampnut,slidethecablejacketupslightly,
tightenthecableclampnut,andcheckthegapagain.
6.Repeatsteps2through5fortheothercable.
3
InstallingtheTractionControl
Linkage
NoPartsRequired
Procedure
1.Removethehairpincotterandwasherfromthelower
endofthespeedcontrolrodandinsertthelowerend
oftherodintothelowerlinkarmsothatthebentend
ofthespeedcontrolrodfacesrearward(Figure11).
Figure11
2.Securethelowerendofthespeedcontrolrodwiththe
washerandhairpincotterthatyoupreviouslyremoved.
3.Removethehairpincotterandtheouterwasherfrom
thetrunnionontheupperendofthespeedcontrol
rod(Figure12).
9
