Setup
1
InstallingtheUpperHandle
NoPartsRequired
Procedure
g293415
2
Installingthe
Wheel-Clutch-CableEnds
NoPartsRequired
Procedure
1.Routeeithertheleftorrightcableendoverthe
lowerhandleandinsertthecableendintothe
holeinthecorrespondingwheel-clutchlever
(Figure5).
g001303
Figure5
1.Wheel-clutchlever
2.Removethenutandwasherfromthehandle,
attachthecableclamponthecabletothe
handle,installthewasherandthenut,and
tightenthenutbyhand(Figure6).
g001304
Figure6
1.Cableclamp(2)
Important:Ensurethatthecurvedsideof
thecableclampisagainstthehandleand
thatthecableisroutedbelowtheclampbolt.
Thecablemustbeinastraightlinefromthe
cableclamptothepointwhereitattachesto
thewheel-clutchlever.
3.Pullthecablejacketdowngentlyuntilthe
wheel-clutchleverisdownandtheslackisout
ofthecable,thentightenthecable-clampnut
securely(Figure7).
